Description

We now stock the new Sanlight Evo range, units currently available in the following options:

250W SANlight EVO 4 120, 4 modules, 1m length.

320W SANlight EVO 5 120. 5 modules, 1m length.

320W SANlight Evo 5 150. 5 Modules, 1.3m length.

We also stock the new Dimmers for the SANlight EVO range and power cables available HERE.

With the EVO-Series, we present you the top of the evolution in LED luminaires for the cultivation of plants. All experience from in-house and external research has been combined with the latest technology.

As a user you benefit from maximum flexibility, best system efficiency and sustainable lifetime with the EVO-Series. No matter if you want to light a small area, a professional indoor production or a whole greenhouse. With the EVO-Series we can offer you the right grow light for every application.

Of course, with the EVO-Series SANlight offer an advanced efficiency of more than 3µmol/J on module level. However, much more attention was paid to yield per area and time during development. In countless empirical trials with various yielding plants, the spectrum was optimized as best as possible. The resulting broadband light spectrum extends beyond the conventional PAR range and offers a Far Red to Red ratio that positively influences photo-morphogenesis, and thus also the quality and quantity of the harvest.

KEY POINTS:

  • IP65 waterproofing for humid environments
  • Excellent fixture efficiency of more than 3µmol/J
  • Geometric optimised optics
  • Quality IP65 Connectors
  • Optimised passive cooling heat sinks
  • Optional Dimmer and Sunrise Simulation
  • Separate power cable required and equipment

Protection and light control.

In the development of the EVO series, the protective and light-directing secondary optics were optimized to the geometric dimensions of the luminaire. This results in an incredibly homogeneous illumination with the best light intensity (PPFD). The asymmetric secondary optics also minimize photon transport losses to the plants and protect the Leds from the environmental influences to which the luminaire is exposed during plant cultivation. Sulfur and other chemical substances cannot penetrate to the LED. Thus, oxidation of the led chip reflector is prevented. The optics can be easily cleaned. The protection and the possibility of cleaning guarantee you a constant light output for many years.

The Finest technology.

From an almost unmanageable selection of Leds which are available on the market, we have selected only the best for you. For red and far-red Leds, we have chosen, as in years past, the latest OSRAM High Power Leds. For white LEDs we were convinced by the patented WICOP technology from Seoul Semiconductor. The LEDS with this technology are characterized by the renunciation of lead frames and silver by special robustness with best efficiency.

Ready-to-dim.

Each model of the EVO series is “ready-to-dim”. This means that the luminaire is compatible with the typical control systems used in greenhouse technology.
Alternatively, you can retrofit the luminaire with magnetic dimmer or Bluethooth dimmer.
Compared to rotary potentiometers, our solutions work wear-free and humidity and water cannot harm them.

Specifications.

SANLIGHT EVO 4-120

EVO 4-120
Power consumption 255
PPF* 696
Weight 5.1
Length (mm) 1018
Width (mm) 291
Height (mm) 116
Protection class IP65

*in the emission wavelength range from 400 – 780 nm

SANLIGHT EVO 5 150

EVO 5-150
Power consumption (W) 320
PPF* 870
Weight (kg) 6.4
Length (mm) 1318
Width (mm) 291
Height (mm) 116
Protection class IP65

*in the emission wavelength range from 400 – 780 nm

SANLIGHT EVO 5 120 SPECIFICATIONS

Power consumption 320
PPF* 870
Weight (kg) 5.9
Length (mm) 1018
Width (mm) 291
Height (mm) 116
Protection class IP65

*in the emission wavelength range from 400 – 780 nm
